| Code | Fiber Diameter | Cable Diameter |
Core Number |
Fiber Manufacturer | Reel Length | Outer Jacket Material |
|---|---|---|---|---|---|---|
| EF30*4 | 0.75mm(0.03") | 3.0mm(0.12") | 4 | DEUFO | 450m(1476'') | PVC |
| EF30*7 | 0.75mm(0.03") | 4.0mm(0.16") | 7 | 450m(1476') | PVC | |
| EF30*14 | 0.75mm(0.03") | 5.0mm(0.20") | 14 | 300m(984') | PVC | |
| EF30*25 | 0.75mm(0.03") | 6.0mm(0.24") | 25 | 100m(328') | PVC | |
| EF30*42 | 0.75mm(0.03") | 8.0mm(0.31") | 42 | 100m(328') | PVC | |
| EF30*50 | 0.75mm(0.03") | 8.0mm(0.31") | 50 | 100m(328') | PVC | |
| EF30*75 | 0.75mm(0.03") | 12.0mm(0.47") | 75 | 100m(328') | PVC | |
| EF30*126 | 0.75mm(0.03") | 14.0mm(0.55") | 126 | 100m(328') | PVC |
| Code | Fiber Diameter | Cable Diameter |
Core Number |
Fiber Manufacturer | Reel Length | Outer Jacket Material |
|---|---|---|---|---|---|---|
| CK30*4 | 0.75mm(0.03") | 3.0mm(0.12") | 4 | Mitsubishi Eska | 450m(1476'') | PVC |
| CK30*7 | 0.75mm(0.03") | 4.0mm(0.16") | 7 | 450m(1476') | PVC | |
| CK30*14 | 0.75mm(0.03") | 5.0mm(0.20") | 14 | 300m(984') | PVC | |
| CK30*25 | 0.75mm(0.03") | 6.0mm(0.24") | 25 | 100m(328') | PVC | |
| CK30*42 | 0.75mm(0.03") | 8.0mm(0.31") | 42 | 100m(328') | PVC | |
| CK30*50 | 0.75mm(0.03") | 8.0mm(0.31") | 50 | 100m(328') | PVC | |
| CK30*75 | 0.75mm(0.03") | 12.0mm(0.47") | 75 | 100m(328') | PVC | |
| CK30*126 | 0.75mm(0.03") | 14.0mm(0.55") | 126 | 100m(328') | PVC |
